Name: 40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-QSFP-40G-LX4
Price: 81.00 USD
Availability: InStock

집 > 상품 > QSFP+ 송수신기 >

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

1270~1330nm QSFP+ Transceiver

4 CWDM Lanes MUX/DEMUX Optical Module

2km Fiber Optic Transceiver

원래 장소:

광동, 중국

브랜드 이름:

HILINK

인증:

CE FCC Rohs

모델 번호:

HL-QSFP-40G-LX4

저희와 연락

인용 을 요청 하십시오

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

제품 세부 정보

제품 이름:

40G QSFP+ 2Km

코터:

이중 LC

데이터 속도:

40g

거리:

2km

온도 범위:

0℃ ~ +70℃

인증:

RoHS Compliant

유형:

광섬유 트랜시버, 40g QSFP+

디지털 진단 기능:

내장

지불 및 배송 조건

최소 주문 수량

1pcs

가격

EXW: 75~87USD/PCS

포장 세부 사항

정전기 가방, 플라스틱 플랫, 소매 박스가 지나서 요구합니다

배달 시간

5-8workingdays

지불 조건

Western Union, T/T, L/C.

공급 능력

100pcs/월

40G QSFP+ SWDM4 Optical Transceiver with 240m/350m Distance Duplex LC Connector and Built-in Digital Diagnostics

최상의 가격을 얻으세요

40Gb/s 150m QSFP+ SR4 트랜시버 광섬유 모듈 MPO 커넥터

최상의 가격을 얻으세요

40Gb/s 100m QSFP+ 광섬유 모듈 바이-다이 듀플렉스 LC 핫 플러그 850/900nm MMF

최상의 가격을 얻으세요

40Gb/s 60km QSFP+ 트랜시버 핫 플러그블 듀플렉스 LC 커넥터 단일 모드

최상의 가격을 얻으세요

저희와 연락

86-755-8317-6243

지금 연락하세요

제품 설명

40Gb/s LX4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Product Description

40Gb/s LX4 IR4 QSFP+ 2km Transceiver Duplex LC SMF/MMF Digital Diagnostics Monitoring

Key Features

Up to 11.2Gbps per channel bandwidth
Aggregate bandwidth of > 40Gbps
Duplex LC connector
Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-SR4/IR4 Standard
QSFP MSA compliant
Maximum link length of 100m on OM3 and 150m on OM4
4 CWDM lanes MUX/DEMUX design
Compliant with QDR/DDR Infiniband data rates
Single +3.3V power supply operating
Built-in digital diagnostic functions
Operating temperature range: 0°C to 70°C
RoHS Compliant

Applications

Rack to rack connections
Data center switches and routers
Metro networks
40G Ethernet links

Technical Details

The HL-QSFP-40G-LX4 transceiver module is designed for 2km (SMF) and 150m (MMF) optical communication applications. Compliant with 40GBASE-SR4 and 40GBASE-LX4 of the IEEE P802.3ba standard, it converts 4 input channels of 10Gb/s electrical data to 4 CWDM optical signals, multiplexing them into a single channel for 40Gb/s optical transmission. On the receiver side, it optically de-multiplexes a 40Gb/s input into 4 CWDM channel signals and converts them to 4 channel output electrical data.

Our Services

We offer OEM and ODM services for custom orders.

Quality Guarantee

All optical transceivers are brand new with new components, never using old or refurbished materials. Each unit undergoes functional and aging tests. We provide a 3-year warranty from the date of shipment.

Product Range

We supply compatible optical transceiver modules including SFP, GBIC, SFP+, XENPAK, X2, XFP, BIDI, CWDM, DWDM and other special modules compatible with most major brands.

Packaging & Shipping

We ship internationally via DHL, FedEx, EMS, TNT, UPS with delivery in 3-7 days.
